PYQs Based test 14: Control Systems

Topics Covered

Sample Questions from this Test

1. Which of the following systems has maximum peak overshoot due to a step input?
   View solution & explanation →
2. The Bode magnitude plot of the transfer function $G\left(s\right)=\frac{K\left(1+0.5s\right)\left(1+as\right)}{s\left(1+\frac{s}{8}\right)\left(1+bs\right)\left(1+\frac{s}{36}\right)}$ is shown below. Note that – 6dB/octave = -20 dB/decade. The value of $\frac{a}{bK}$ is ___________


   View solution & explanation →
3. The root locus of the feedback control system having the real characteristic equation s ²+ 6Ks + 2s + 5 = 0 where K > 0, enters into the real axis at
   View solution & explanation →

Showing 3 of 20 questions. Start the test to attempt all of them.

Test Instructions

• The test contains 20 questions and a total of 32 marks.
• You will have 180 minutes to complete the test. The timer cannot be paused once started.
• Negative marking: 0.25 mark(s) deducted per wrong answer.
• Use the question palette to mark questions for review and navigate freely.
• Detailed solutions and analytics are available immediately after submission.
• This is a free practice test. No login required to attempt.
